Automatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection Disinfection

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SGS
Model Number: A4L160, A3L120, H4L192, H5L240
Trading Properties
Minimum Order Quantity: 40set
Price: 110-160usd/set
Standard Packaging: FCL: Standard exporting packaging; LCL: Wooden box, carton packaging
Delivery Time: in 30 working days after deposit
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 20000sets/week
Product Summary
Product Description: Site selection for laying hens (1) Climate conditions: Detailed understanding of the local meteorological department's average temperature, absolute maximum temperature and absolute minimum temperature, soil freezing depth, average rainfall, maximum wind speed, perennial main ...

Product Details

Highlight:

Automatic Egg Laying Chicken Cages

,

Hot Galvanized Egg Laying Chicken Cages

Product Name: Fully Automatic Poultry Egg And Broiler Chicken Cage
Cage Wire Meterial: Q235 Bridge Steel, 3-6mm Thickness
Wire Mesh Surface: Hot Or Cold Galvanization
Cage Type: A、H Type Chicken Cage
Egg Collecting System: Automatic Egg Collecting System
Life Time: 15-20years
Use: Egg Layer Chicken,laying Hens Chicken Cage
Service: 24 Hours Online
Core Components: Feed Trough, Water Tank, Cage Mesh, Nipple Drinker, Screw, Connecting Pipe Fittings
Product Description

Product Description:

Site selection for laying hens

(1) Climate conditions:

Detailed understanding of the local meteorological department's average temperature, absolute maximum temperature and absolute minimum temperature, soil freezing depth, average rainfall, maximum wind speed, perennial main wind direction, and monthly sunshine hours in the past 5-10 years.

(2) Location:

The site should be located in an area with convenient transportation and flat roads, with a quiet environment around the chicken farm, away from residential areas and noisy factories, and away from slaughterhouses and hospitals. More than 500 meters away from the main road and animal breeding areas, more than 200 meters away from animal clinics, and more than 100 meters away from secondary roads.

(3) Terrain and topography:

Require a high and dry terrain, facing south or southeast, with a certain slope to facilitate lighting, ventilation, and drainage. If building a site on a hillside or hilly area, it can be built on a sunny slope, but the slope should not be too steep. Chicken farms should not be built in low-lying and humid areas, nor should they be built on mountain tops and high slopes. Strive for a square area to minimize the use of lines and pipelines, and minimize or minimize the occupation of arable land.

(4) Soil:

The soil should be sandy loam with good drainage and poor thermal conductivity, and the groundwater level in the external site should be low.

(5) Water source:

The water source in the site is sufficient, and the water quality should meet the hygiene standards for drinking water. It is best to drill deep wells to obtain water. Untreated river and pond water cannot be used for direct drinking by chickens.

(6) Power supply:

The power supply must be stable, reliable, and sufficient. It is best to use dual power supply, otherwise you need to provide your own power generation equipment.



Cage size:

H Type Battery Cages Layer Poultry Farming Equipment
Model L(mm) W(mm) H(mm) Door Birds Qty/Set
3tire 1800 600 430 4 144
4tire 1800 600 430 4 192
3tire 650 625 500 1 54
4tire 650 625 500 1 72



A Type Battery Cages Layer Poultry Farming Equipment

Model L(mm) W(mm) H(mm) Door Birds Qty/Set
3tire 1950 2300 1500 5 90
4tire 1950 2300 1950 5 120
3tire 2150 2300 1600 5 120
4tire 2150 2300 2000 5 160



How to choose a healthy baby chicken?

The quality of chicks is one of the key points to improve the quality of broiler production. Without good quality chicks, it is difficult to achieve good production level even if the management conditions are good. The selection criteria for healthy chicks are:

1, chicks should come from well-managed breeding farms, no vertical transmission of diseases.

2, the chickens should be large in weight and lively in spirit, no dehydration phenomenon such as shriveled feet and wrinkles, especially the chickens that have been transported for a long time should pay attention to check whether they have been dehydrated.

3, the chicken fluff fluffy, bright color, belly fluff can cover the abdomen.

4. Soft and flat abdomen.

5. The umbilical cord is well healed with no inflammation and is covered by fur.



Automatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection Disinfection

Automatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection Disinfection

Precautions of battery chicken cage system

If the stocking density exceeds the number of chicken cages, it will restrict the activities of the chickens and affect the growth and development. Moreover, too many numbers will also affect the air quality of the chicken coops and the service life of the chicken coops, and may also cause the chickens to become stronger. Bullying, pecking and other phenomena occur, so farmers should make reasonable adjustments in time according to the growth stage of the flock.



Automatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection DisinfectionAutomatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection DisinfectionAutomatic Egg Laying Chicken Cages Hot Galvanized With Battery Cage Farming Equipment And Egg Collection Disinfection
