Battery Cage System Features Four Tiers And Is Designed For 120 Birds With Automatic Ventilation.

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SONCAP
Model Number: H4L192/H4B208
Trading Properties
Minimum Order Quantity: 50 sets
Price: 150-288usd/set
Standard Packaging: Standard exporting packaging or according to clients' request
Delivery Time: In 35 working days after deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 80000sets/ month
Product Summary
Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation Introduction Of Battery Chicken Cage For Poultry Layers And Broilers: The European standard battery chicken cage system, one of Silver Star's larger designs, ensures excellent ventilation for chickens. Each door ...

Product Details

Highlight:

120 birds battery cage system

,

four tiers battery cage system

,

automatic ventilation battery cage system

Keywords: Europe Standard Battery Chicken Cage For Poultry Layers And Broilers
Each Door Size: 650x625x440, 1000x1000x440, 1500x1000x440
Birds Capacity: 54-384 Birds/set
Cage Type: Type H Of Battery Chicken Cage
Marketing Type: 2021 New Type Layer And Broiler Poultry Cage
Key Selling Points: More Than 25 Years Of Lifespan
Surface Process: Hot-dip Galvanized Steel
Characteristics: Large Size Poultry Cage, Good Ventilation
Application Industries: Poultry Layer And Broiler Raising Equipment
HS Code: 84362900
Product Description

 Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation





Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:



The European standard battery chicken cage system, one of Silver Star's larger designs, ensures excellent ventilation for chickens.

Each door of the European standard poultry layers battery chicken cage is 650mm long, 625mm deep, and 440mm high, designed to hold nine birds, providing 450 square centimeters per bird.

The dimensions of each door in the European-sized poultry broilers battery chicken cage are 1000mm in length, 1000mm in depth, and 440mm in height, with a capacity of twenty birds per door, offering 500 square centimeters per bird.





Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:



1. The use of Q235 bridge wire in poultry layers and broilers battery chicken cages guarantees strength and minimizes the risk of bending in the future.

2. Ensuring proper airflow, the large-sized battery chicken cage systems provide a beneficial breeding environment for layers and broilers chickens.

3. High-density breeding, saving land and investment. Battery chicken cage for poultry layers and broilers is easier to observe the birds, easy to gather or weak in selection

4.The entire set of battery chicken cage equipment is fabricated using hot-dip galvanized processing, ensuring corrosion resistance and a lifespan of over 25 years.

5. By ensuring sufficient feed and optimal water levels, and promoting uniform health among chickens, it is possible to minimize their need for exercise, thereby saving energy and reducing feed usage.

6. With chicken manure effectively separated and directed to the belt, dust levels in the chicken house are notably reduced, reducing the likelihood of disease transmission from manure and significantly decreasing bird mortality rates.

7. It is well-suited for both closed and open chicken houses, with automated ventilation and temperature control to address challenges posed by hot weather conditions effectively.

8. Implementing the belt cleaning method effectively enhances air quality in the chicken house, thereby reducing the incidence of certain diseases and ensuring optimal safety measures.

9. Egg breakage rate,high cleanliness





Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:



Type H Poultry Layers Battery Chicken Cage
Model  Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3L54 1 9 3 54 450 650x625x440 650x1250x2220
H4L72 1 9 4 72 450 650x625x440 650x1250x2870
H5L90 1 9 5 90 450 650x625x440 650x1250x3520
H6L108 1 9 6 108 450 650x625x440 650x1250x4170
H8L144 1 9 8 144 450 650x625x440 650x1250x5470
Full equipment H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system



Type H Poultry Broilers Battery Chicken Cage
Model Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3B60 1 20 3 60 500 1000x1000x440 1000x1000x2200
H4B80 1 20 4 80 500 1000x1000x440 1000x1000x2850
H3B90 1 30 3 90 500 1500x1000x440 1500x1000x2200
H4B120 1 30 4 120 500 1500x1000x440 1500x1000x2850
H3B156 4 13 3 156 500 740X850X440 1480X1750X2800
H4B208 4 13 4 208 500 740X850X440 1480X1750X3600
Full equipment H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system




Why Use Battery Chicken Cage In Poultry Production?


1. Minimize feed waste and optimize productivity in layer farming.
2. Increased production
3.
Enhanced flock management
4. Cut down on labor costs
5. Prevention of accidental mortalities
6. Optimized poultry waste management
7. The cages systems are reusable



Battery Cage System Features Four Tiers And Is Designed For 120 Birds With Automatic Ventilation.
