Automated Ventilated Layer Cage System Accommodates 120 Birds Across Four Tiers

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SONCAP
Model Number: H4L192/H4B208
Trading Properties
Minimum Order Quantity: 50 sets
Price: 150-288usd/set
Standard Packaging: Standard exporting packaging or according to clients' request
Delivery Time: In 35 working days after deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 80000sets/ month
Product Summary
Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation Introduction Of Battery Chicken Cage For Poultry Layers And Broilers: European standard battery chickn cage sytsem is one of Silver Star's big size designs to assure good ventilation for chickens. The European...

Product Details

Highlight:

Automated Ventilated Layer Cage System

,

Four Tiers Layer Cage System

,

120 Birds Layer Cage System

Keywords: Europe Standard Battery Chicken Cage For Poultry Layers And Broilers
Each Door Size: 650x625x440, 1000x1000x440, 1500x1000x440
Birds Capacity: 54-384 Birds/set
Cage Type: Type H Of Battery Chicken Cage
Marketing Type: 2021 New Type Layer And Broiler Poultry Cage
Key Selling Points: More Than 25 Years Of Lifespan
Surface Process: Hot-dip Galvanized Steel
Characteristics: Large Size Poultry Cage, Good Ventilation
Application Industries: Poultry Layer And Broiler Raising Equipment
HS Code: 84362900
Product Description

 Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation





Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:



European standard battery chickn cage sytsem is one of Silver Star's big size designs to assure good ventilation for chickens.

The European-sized poultry layers battery chicken cage features doors that measure 650mm in length, 625mm in depth, and 440mm in height, accommodating nine birds per door with 450 square centimeters per bird.

Each door of the European standard poultry broilers battery chicken cage is 1000mm long, 1000mm deep, and 440mm high, designed to hold twenty birds, providing 500 square centimeters per bird.





Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:



1. Featuring Q235 bridge wire, the poultry layers and broilers battery chicken cage offers long-term durability and is not prone to bending.

2. The ample size of the battery chicken cage systems promotes good ventilation, establishing a conducive breeding environment for layers and broilers chickens.

3. Adopting battery chicken cages for poultry layers and broilers in high-density breeding saves land and investment, making it easier to observe, select, and manage the birds, especially the weaker ones.

4.Full sets of battery chicken cage equipment is made of hot-dip galvanized processing, which is corrosion-resistant and ensures over 25 years lifespan.

5. Providing ample feed and maintaining proper hydration levels while ensuring uniform health among chickens helps minimize their exercise requirements, conserving energy and reducing feed consumption.

6. The segregation of chicken manure, which drops directly onto the belt, leads to a substantial reduction in dust within the chicken house, minimizes disease transmission risks associated with manure, and markedly lowers bird mortality rates.

7. Designed for use in both closed and open chicken houses, this system features automated ventilation and temperature control to effectively manage issues arising from hot weather conditions.

8.  By employing the belt cleaning method, air quality in the chicken house is markedly improved, resulting in fewer occurrences of certain diseases and maintaining high safety standards.

9. Maintaining high cleanliness and minimizing egg breakage.





Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:



Type H Poultry Layers Battery Chicken Cage
Model  Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3L54 1 9 3 54 450 650x625x440 650x1250x2220
H4L72 1 9 4 72 450 650x625x440 650x1250x2870
H5L90 1 9 5 90 450 650x625x440 650x1250x3520
H6L108 1 9 6 108 450 650x625x440 650x1250x4170
H8L144 1 9 8 144 450 650x625x440 650x1250x5470
Full equipment H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system



Type H Poultry Broilers Battery Chicken Cage
Model Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3B60 1 20 3 60 500 1000x1000x440 1000x1000x2200
H4B80 1 20 4 80 500 1000x1000x440 1000x1000x2850
H3B90 1 30 3 90 500 1500x1000x440 1500x1000x2200
H4B120 1 30 4 120 500 1500x1000x440 1500x1000x2850
H3B156 4 13 3 156 500 740X850X440 1480X1750X2800
H4B208 4 13 4 208 500 740X850X440 1480X1750X3600
Full equipment H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system




Why Use Battery Chicken Cage In Poultry Production?


1. Reduce feed wastage and maximize productivity in layer production
2. Increased production
3.
Improved overall flock management
4. Lower labor expenses
5. Zero unintended fatalities
6. Better management of poultry waste
7. These cages can be used again.
