Galvanized A-Type Laying Hens H-Type Battery Cage And Automatic Breeding System
Product Details
H-Type Battery Cage
,Laying Hens H-Type Battery Cage
Fully automatic A-type H-type laying cage
Product Desc
1) silver star layer cages poultry are manufactured with anti-corrosive galvanized steel and wire cage partitions
2) The complete ventilation equipment brings a better living environment for the chicken house
3) Each layer of chicken manure is treated separately, which greatly reduces the pollution to the environment and also improves the utilization rate of chicken manure air drying
4) Closed breeding avoids the mortality caused by fighting and infection among chickens
5) Automatic egg collection system, reduce the damage rate of manual egg collection
6)The chicken cage features a unique horizontal door design, providing a larger door space and allowing flexible feeding positions. This effectively reduces crowding during feeding and ensures more even feeding among chickens.
It saves feed and reduces stress responses in laying hens and the chance of chicken injuries. It also conserves water and has a low egg breaking rate.
7)The cage design promotes good ventilation and lighting, which benefits chicken growth. It allows for high feeding density and requires minimal space, resulting in high intensification and good economic benefits. It is suitable for all types of chicken houses (open, semi-open, and closed).
8)The chicken cage's horizontal door design offers a spacious entry, allowing flexible changes in feeding positions, which helps
Cage size:
| A Type Battery Cages Layer Poultry Farming Equipment | |||||
| Model | Length(mm) | Width(mm) | Heigh(mm) | Door Qty | Birds Qty/Set |
| 3 Tiers | 1950 | 2300 | 1500 | 5 | 90 |
| 4 Tiers | 1950 | 2300 | 1900 | 5 | 120 |
| 3 Tiers | 1950 | 2300 | 1600 | 4 | 96 |
| 4 Tiers | 1950 | 2300 | 2000 | 4 | 128 |
| 3 Tiers | 2150 | 2300 | 1600 | 5 | 120 |
| 4Tiers | 2150 | 2300 | 2000 | 5 | 160 |
| 3Tiers | 2150 | 2360 | 1600 | 5 | 120 |
| 4 Tiers | 2150 | 2360 | 2000 | 5 | 160 |
| 3 Tiers | 1720 | 2360 | 1600 | 4 | 96 |
| 4 Tiers | 1720 | 2360 | 2000 | 4 | 128 |
| H Frame Layer Poultry Farming Equipment | |||||||
| Cage size | Door No. /cage | Chicken No. /door | No. of tiers | Birds qty/set | Area per bird (cm2/bird) | Each door Size(mm) | Unit Cage Size(mm) |
| 1800*600*430 | 4 | 6 | 3 | 144 | 450 | 450x600x430 | 1800x1200x2140 |
| 1800*600*430 | 4 | 6 | 4 | 192 | 450 | 450x600x430 | 1800x1200x2790 |
| 1800*600*430 | 4 | 6 | 5 | 240 | 450 | 450x600x430 | 1800x1200x3440 |
| 1800*600*430 | 4 | 6 | 6 | 288 | 450 | 450x600x430 | 1800x1200x4090 |
| 1800*600*430 | 4 | 6 | 8 | 384 | 450 | 450x600x430 | 1800x1200x5390 |
| 650*625*500 | 1 | 9 | 3 | 54 | 450 | 650x625x500 | 650x1250x2220 |
| 650*625*500 | 1 | 9 | 4 | 72 | 450 | 650x625x500 | 650x1250x2870 |
| 650*625*500 | 1 | 9 | 5 | 90 | 450 | 650x625x500 | 650x1250x3520 |
| 650*625*500 | 1 | 9 | 6 | 108 | 450 | 650x625x500 | 650x1250x4170 |
| 650*625*500 | 1 | 9 | 8 | 144 | 450 | 650x625x500 | 650x1250x5470 |
H-type chicken coop, also known as multi-layer laminated chicken coop, has many advantages such as large breeding amount per unit area, high land utilization rate, low labor cost, low staff dynamic intensity, low risk of disease transmission, simple fecal treatment, cleanliness and hygiene. At the same time, the H-type chicken cage can also be well combined with the modern Internet and intelligent technology, and more intelligent information technology can be applied to the preparation of livestock breeding, improve the level of chicken intensification and automation, and promote the technological upgrading of the chicken industry
Precautions of battery chicken cage system
If the stocking density exceeds the number of chicken cages, it will restrict the activities of the chickens and affect the growth and development. Moreover, too many numbers will also affect the air quality of the chicken coops and the service life of the chicken coops, and may also cause the chickens to become stronger. Bullying, pecking and other phenomena occur, so farmers should make reasonable adjustments in time according to the growth stage of the flock.
-
