Resilient Medium Broiler Coop With Ventilation Features , Ensures Optimal Chick Management

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO 9001
Model Number: H type cage
Trading Properties
Minimum Order Quantity: 10
Price: 100 USD
Standard Packaging: container, wooden case
Delivery Time: 20-40 days
Payment Terms: T/T
Supply Ability: 100 set 30 days
Product Summary
High brood survival rates are guaranteed with chicken layer cages, perfect for managing small chicks in broiler farming. management The layer chicken cage Light cages for light laying hens such as Hyline white hens and Dicca white hens, and medium cages for medium laying hens like Hyline brown hens ...

Product Details

Highlight:

Resilient Medium Broiler Coop

,

Medium Broiler Coop With Ventilation

Name: Chicken Feeder Cages For Layers
Product Name: Cages For Layers
Application: Poultry Field Cages For Layers
Material: Hot Dip Galvanized Cages For Layers
Color: Silver Cages For Layers
Usage: Chicken Raising Cages For Layers
Feature: Durable Cages For Layers
Advantage: Long Time Used Cages For Layers
Size: 650*1250*2300(cm) Cages For Layers
Capacity: 200-300 Chickens/set Cages For Layers
Product Description

High brood survival rates are guaranteed with chicken layer cages, perfect for managing small chicks in broiler farming.



management



The layer chicken cage

Light cages for light laying hens such as Hyline white hens and Dicca white hens, and medium cages for medium laying hens like Hyline brown hens and Isha brown hens, are currently available, mainly consisting of three full or half steps.

(1) Cage frame: provides the foundational support for the cage body, including a beam and diagonal support. These are typically made from angle steel or channel steel, with a thickness between 2.0 and 2.5 mm.

(2) The chicken cage is constructed using cold-drawn steel wire, spot welded, galvanized, and assembled, incorporating the top net, bottom net, front net, back net, and cage door. Typically, the front net and top net are pressed together, as are the back net and bottom net, with a separate single net. The cage door is part of the front net or the top net, with options for some doors to be removed or flipped. The cage bottom net is sloped at an angle of 6° to 10°, extending outside the cage by 12 to 16 cm to form the egg tray. Cage specifications include a front height ranging from 40 to 45 cm and a depth of about 45 cm, with each small cage housing 3 to 5 chickens.



Multi-layer coops can promote the health of chickens

Many poultry farmers do not get healthy results from raising chickens because they neglect the use of multi-layer coops. Multi-layer coops are a great way to keep chickens healthy and promote their reproduction.

The initial multi-storey coop wasn't merely a structure with a metal mesh floor and heating elements. A well-designed multi-layer chicken coop differs significantly from a standard wire cage. The wire flooring is engineered to allow for easy fecal leakage, effectively eliminating waste around the flock and reducing the potential for fecal-borne diseases. This ensures the chickens remain healthy, safeguarding the farmers' investments.



Increase egg production

Productivity is higher in chickens that are healthy compared to those raised in less favorable conditions, and using enrichment cages can boost egg production potential.

Recent statistics show that about 60 percent of eggs utilized in foods such as mayonnaise, sandwiches, and cakes are produced by caged chickens. This data implies that chickens tend to lay eggs more frequently in cages than in other breeding environments, with multi-layer cage systems favored to increase egg production.



Product introduction



Henan silver star cage net introduction, Tailored for laying and breeding hens, the 1250 type frame layer cage features cages that are 650 mm long and 1250 mm wide. Each cage includes a door measuring 650 mm long, 650 mm deep, and 500 mm high, designed to offer a spacious environment for maximum comfort. The structure is intricately engineered to enhance welfare, supporting up to 9 animals per door. Each chicken occupies 452 square centimeters of space, and the feeding capacity of each cage reaches 18 birds.



Each three-layer compartment has a breeding capacity of 54 birds, and each enclosure can accommodate either 72 or 90 birds. A six-floor enclosure typically supports 108 birds. The standard setup comprises four layers, with optional multilayer partitions available in configurations such as an eight-layer duplex (4 plus 4) or a nine-layer triple (3 plus 3 plus 3), aimed at minimizing housing costs and maximizing overall value. For further details on related products and compatible automatic equipment, please inquire.





3-tiers 0.65*1.25*2.65 m 54  chickens
4-tiers 0.65*1.25*3.3 m 72  chickens
5-tiers 0.65*1.25*4.6 m 90  chickens
6-tiers 0.65*1.25*4.9 m 108 chicekns
7-tiers 0.65*1.25*5.5 m 126 chickens
8-tiers 0.65*1.25*6.2 m 144 chickens
9-tiers 0.65*1.25*7.2 m 162 chickens





Resilient Medium Broiler Coop With Ventilation Features , Ensures Optimal Chick ManagementResilient Medium Broiler Coop With Ventilation Features , Ensures Optimal Chick Management
