Long-Lasting Broiler Housing Layer Chicken Cage For Easy Access And Cleaning For Small Chick Care

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO 9001
Model Number: H type cage
Trading Properties
Minimum Order Quantity: 10
Price: 100 USD
Standard Packaging: container, wooden case
Delivery Time: 20-40 days
Payment Terms: T/T
Supply Ability: 100 set 30 days
Product Summary
Chicken Layer Cage High Brood Survival Rate Broiler Cage For Little Chick Medium Broiler Cage For Little Chick Management management The layer chicken cage Currently, there are light cages for light laying hens such as Hyline white hens and Dicca white hens, and medium cages for medium laying hens ...

Product Details

Highlight:

Broiler Housing Layer Chicken Cage

,

Layer Chicken Cage Easy Access

Name: Chicken Feeder Cages For Layers
Product Name: Cages For Layers
Application: Poultry Field Cages For Layers
Material: Hot Dip Galvanized Cages For Layers
Color: Silver Cages For Layers
Usage: Chicken Raising Cages For Layers
Feature: Durable Cages For Layers
Advantage: Long Time Used Cages For Layers
Size: 650*1250*2300(cm) Cages For Layers
Capacity: 200-300 Chickens/set Cages For Layers
Product Description

Chicken Layer Cage High Brood Survival Rate Broiler Cage For Little Chick

Medium Broiler Cage For Little Chick Management



management



The layer chicken cage

Currently, there are light cages for light laying hens such as Hyline white hens and Dicca white hens, and medium cages for medium laying hens like Hyline brown hens and Isha brown hens, typically consisting of three full or half steps.

(1) Cage frame: acts as the structural support of the cage body, made up of a beam and diagonal support. These components are usually constructed from angle steel or channel steel, with a thickness ranging from 2.0 to 2.5 mm.

(2) cage body: The chicken cage is constructed of cold-drawn steel wire, spot welded, galvanized, and then assembled with components including the top net, bottom net, front net, back net, and cage door. Typically, the front net and top net are joined, as are the back net and bottom net, with a separate single net. The cage door is integrated into either the front net or the top net, with some doors being removable or reversible. The cage bottom net is sloped at an angle of 6° to 10°, extending out of the cage by 12 to 16 cm to create the egg tray. Cage specifications include a front height ranging from 40 to 45 cm and a depth of approximately 45 cm, suitable for housing 3 to 5 chickens per small cage.



Multi-layer coops can promote the health of chickens

Lack of attention to multi-layer coops contributes to poultry farmers not achieving healthy outcomes in chicken raising. These coops are instrumental in supporting chicken health and fostering successful reproduction.

The initial multi-storey coop wasn't merely equipped with a metal mesh floor and basic heating elements. The design of a top-tier multi-layer chicken coop differs substantially from that of a standard wire cage. Its wire floor is meticulously designed to enable efficient fecal drainage, effectively eliminating waste buildup around the flock and minimizing the potential for fecal-borne diseases. This proactive measure ensures the chickens remain healthy, thereby safeguarding the farmers' livelihoods.



Increase egg production

Healthy chickens are more productive than those raised in unhealthy conditions, and enrichment cages increase the potential for egg production.

Recent estimates indicate that 60 percent of eggs used in products like mayonnaise, sandwiches, and cakes are sourced from chickens kept in cages, suggesting a preference for cage-based egg laying over other breeding methods, particularly using multi-layer cages to enhance egg production.



Product introduction



Henan silver star cage net introduction, Designed for laying and breeding hens, the 1250 type frame layer cage features cages that are 650 mm long and 1250 mm wide. Each cage is equipped with a door measuring 650 mm long, 650 mm deep, and 500 mm high, ensuring ample space for comfort. The cages are engineered with precise structural details to promote welfare, allowing for up to 9 animals per door. Each chicken occupies 452 square centimeters, and the feeding capacity per cage reaches 18 birds.



Each three-layer compartment has a capacity of 54 birds, with each enclosure accommodating either 72 or 90 birds. A six-floor enclosure typically supports 108 birds. The standard configuration consists of four layers, with optional multilayer partition structures available in configurations such as an eight-layer duplex (4 plus 4) or a nine-layer triple (3 plus 3 plus 3), intended to lower housing costs and improve overall value. For more information on related products and matching automatic equipment, please inquire.







3-tiers 0.65*1.25*2.65 m 54  chickens
4-tiers 0.65*1.25*3.3 m 72  chickens
5-tiers 0.65*1.25*4.6 m 90  chickens
6-tiers 0.65*1.25*4.9 m 108 chicekns
7-tiers 0.65*1.25*5.5 m 126 chickens
8-tiers 0.65*1.25*6.2 m 144 chickens
9-tiers 0.65*1.25*7.2 m 162 chickens
