Four-tier Ventilated Automatic Layer Cage System For 120 Chickens.

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SONCAP
Model Number: H4L192/H4B208
Trading Properties
Minimum Order Quantity: 50 sets
Price: 150-288usd/set
Standard Packaging: Standard exporting packaging or according to clients' request
Delivery Time: In 35 working days after deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 80000sets/ month
Product Summary
Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation Introduction Of Battery Chicken Cage For Poultry Layers And Broilers: Ensuring proper ventilation for chickens, the European standard battery chicken cage system is a significant design by Silver Star. This ...

Product Details

Highlight:

Four-tier layer cage system

,

Automatic layer cage system

,

120 chickens layer cage system

Keywords: Europe Standard Battery Chicken Cage For Poultry Layers And Broilers
Each Door Size: 650x625x440, 1000x1000x440, 1500x1000x440
Birds Capacity: 54-384 Birds/set
Cage Type: Type H Of Battery Chicken Cage
Marketing Type: 2021 New Type Layer And Broiler Poultry Cage
Key Selling Points: More Than 25 Years Of Lifespan
Surface Process: Hot-dip Galvanized Steel
Characteristics: Large Size Poultry Cage, Good Ventilation
Application Industries: Poultry Layer And Broiler Raising Equipment
HS Code: 84362900
Product Description

 Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation





Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:



Ensuring proper ventilation for chickens, the European standard battery chicken cage system is a significant design by Silver Star.

This European-sized poultry layers battery chicken cage has doors that are 650mm long, 625mm deep, and 440mm high, each accommodating nine birds with an area of 450 square centimeters per bird.

This European-sized poultry broilers battery chicken cage has doors that are 1000mm long, 1000mm deep, and 440mm high, each accommodating twenty birds with an area of 500 square centimeters per bird.



Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:



1. The use of Q235 bridge wire in poultry layers and broilers battery chicken cages guarantees strength and minimizes the risk of bending in the future.

2. The ample size of the battery chicken cage systems promotes good ventilation, establishing a conducive breeding environment for layers and broilers chickens.

3. By using battery chicken cages for high-density breeding, land and investment are saved, and it becomes simpler to monitor the birds and select or gather the weaker ones.

4.The entire array of battery chicken cage equipment undergoes hot-dip galvanized processing, which offers corrosion resistance and a lifespan of over 25 years.

5.With sufficient feed, proper hydration, and consistent health among chickens, the need for physical activity is minimized, leading to energy savings and reduced feed expenditure.

6. The complete separation of chicken manure, allowing it to fall directly onto the belt, results in a considerable decrease in dust within the chicken house, minimizing the potential for disease transmission from manure and significantly reducing bird mortality.

7. It is well-suited for both closed and open chicken houses, with automated ventilation and temperature control to address challenges posed by hot weather conditions effectively.

8.  By employing the belt cleaning method, air quality in the chicken house is markedly improved, resulting in fewer occurrences of certain diseases and maintaining high safety standards.

9. Achieving high cleanliness standards with a low egg breakage rate.





Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:



Type H Poultry Layers Battery Chicken Cage
Model  Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3L54 1 9 3 54 450 650x625x440 650x1250x2220
H4L72 1 9 4 72 450 650x625x440 650x1250x2870
H5L90 1 9 5 90 450 650x625x440 650x1250x3520
H6L108 1 9 6 108 450 650x625x440 650x1250x4170
H8L144 1 9 8 144 450 650x625x440 650x1250x5470
Full equipment H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system



Type H Poultry Broilers Battery Chicken Cage
Model Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3B60 1 20 3 60 500 1000x1000x440 1000x1000x2200
H4B80 1 20 4 80 500 1000x1000x440 1000x1000x2850
H3B90 1 30 3 90 500 1500x1000x440 1500x1000x2200
H4B120 1 30 4 120 500 1500x1000x440 1500x1000x2850
H3B156 4 13 3 156 500 740X850X440 1480X1750X2800
H4B208 4 13 4 208 500 740X850X440 1480X1750X3600
Full equipment H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system




Why Use Battery Chicken Cage In Poultry Production?


1. Lower feed wastage and boost productivity in layer poultry farming.
2. Increased production
3.
More effective flock management
4. Decrease labor expenditures
5. Prevention of accidental mortalities
6. Better management of poultry waste
7. Cage systems are reusable.



Four-tier Ventilated Automatic Layer Cage System For 120 Chickens.
