Automatic Layer Cage System With Ventilation 4 Levels Capacity For 120 Chickens

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SONCAP
Model Number: H4L192/H4B208
Trading Properties
Minimum Order Quantity: 50 sets
Price: 150-288usd/set
Standard Packaging: Standard exporting packaging or according to clients' request
Delivery Time: In 35 working days after deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 80000sets/ month
Product Summary
Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation Introduction Of Battery Chicken Cage For Poultry Layers And Broilers: One of Silver Star's spacious designs, the European standard battery chicken cage system, guarantees superior airflow for chickens. Each door ...

Product Details

Highlight:

4 levels layer cage system

,

Automatic layer cage system

,

120 chickens layer cage system

Keywords: Europe Standard Battery Chicken Cage For Poultry Layers And Broilers
Each Door Size: 650x625x440, 1000x1000x440, 1500x1000x440
Birds Capacity: 54-384 Birds/set
Cage Type: Type H Of Battery Chicken Cage
Marketing Type: 2021 New Type Layer And Broiler Poultry Cage
Key Selling Points: More Than 25 Years Of Lifespan
Surface Process: Hot-dip Galvanized Steel
Characteristics: Large Size Poultry Cage, Good Ventilation
Application Industries: Poultry Layer And Broiler Raising Equipment
HS Code: 84362900
Product Description

 Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation





Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:



One of Silver Star's spacious designs, the European standard battery chicken cage system, guarantees superior airflow for chickens.

Each door of the European standard poultry layers battery chicken cage is 650mm long, 625mm deep, and 440mm high, designed to hold nine birds, providing 450 square centimeters per bird.

The dimensions of each door in the European-sized poultry broilers battery chicken cage are 1000mm in length, 1000mm in depth, and 440mm in height, with a capacity of twenty birds per door, offering 500 square centimeters per bird.



Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:



1. Featuring Q235 bridge wire, the poultry layers and broilers battery chicken cage offers long-term durability and is not prone to bending.

2. With their large dimensions, the battery chicken cage systems offer superior ventilation, contributing to a favorable breeding environment for both layers and broilers chickens.

3. The high-density breeding approach using battery chicken cages for layers and broilers conserves land and investment, providing ease in bird observation and selection of weaker birds.

4.Utilizing hot-dip galvanized processing, the complete battery chicken cage equipment is corrosion-resistant and designed to last for more than 25 years.

5. When chickens receive adequate feed and maintain good hydration levels, along with uniform health, it limits their need for exercise, conserves energy, and reduces feed consumption.

6. With chicken manure effectively separated and directed to the belt, dust levels in the chicken house are notably reduced, reducing the likelihood of disease transmission from manure and significantly decreasing bird mortality rates.

7. Designed for use in both closed and open chicken houses, this system features automated ventilation and temperature control to effectively manage issues arising from hot weather conditions.

8.  The adoption of the belt cleaning method leads to a substantial improvement in air quality within the chicken house, thereby decreasing the occurrence of certain diseases and ensuring high levels of safety.

9. Keeping the egg breakage rate low and ensuring high levels of cleanliness.





Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:



Type H Poultry Layers Battery Chicken Cage
Model  Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3L54 1 9 3 54 450 650x625x440 650x1250x2220
H4L72 1 9 4 72 450 650x625x440 650x1250x2870
H5L90 1 9 5 90 450 650x625x440 650x1250x3520
H6L108 1 9 6 108 450 650x625x440 650x1250x4170
H8L144 1 9 8 144 450 650x625x440 650x1250x5470
Full equipment H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system



Type H Poultry Broilers Battery Chicken Cage
Model Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3B60 1 20 3 60 500 1000x1000x440 1000x1000x2200
H4B80 1 20 4 80 500 1000x1000x440 1000x1000x2850
H3B90 1 30 3 90 500 1500x1000x440 1500x1000x2200
H4B120 1 30 4 120 500 1500x1000x440 1500x1000x2850
H3B156 4 13 3 156 500 740X850X440 1480X1750X2800
H4B208 4 13 4 208 500 740X850X440 1480X1750X3600
Full equipment H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system




Why Use Battery Chicken Cage In Poultry Production?


1. Cut down on feed wastage and increase efficiency in layer operations.
2. Increased production
3.
Superior flock management
4. Cut down on labor costs
5. Zero unintended fatalities
6. More efficient handling of poultry waste
7. The cages are designed for reuse.
