Automatic Ventilation System For Layered Chicken Cages 4 Tiers Holds 120 Birds

Basic Properties
Place of Origin: China
Brand Name: Silver Star
Certification: ISO9001, SONCAP
Model Number: H4L192/H4B208
Trading Properties
Minimum Order Quantity: 50 sets
Price: 150-288usd/set
Standard Packaging: Standard exporting packaging or according to clients' request
Delivery Time: In 35 working days after deposit
Payment Terms: T/T, Western Union, L/C, D/A, D/P
Supply Ability: 80000sets/ month
Product Summary
Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation Introduction Of Battery Chicken Cage For Poultry Layers And Broilers: The European standard battery chicken cage system, one of Silver Star's larger designs, ensures excellent ventilation for chickens. The ...

Product Details

Highlight:

4 tiers Automatic ventilation system

,

Layered chicken cages Automatic ventilation system

,

120 birds Automatic ventilation system

Keywords: Europe Standard Battery Chicken Cage For Poultry Layers And Broilers
Each Door Size: 650x625x440, 1000x1000x440, 1500x1000x440
Birds Capacity: 54-384 Birds/set
Cage Type: Type H Of Battery Chicken Cage
Marketing Type: 2021 New Type Layer And Broiler Poultry Cage
Key Selling Points: More Than 25 Years Of Lifespan
Surface Process: Hot-dip Galvanized Steel
Characteristics: Large Size Poultry Cage, Good Ventilation
Application Industries: Poultry Layer And Broiler Raising Equipment
HS Code: 84362900
Product Description

 Europe Standard Battery Chicken Cage For Poultry Layers And Broilers, Good Ventilation





Introduction Of Battery Chicken Cage For Poultry Layers And Broilers:



The European standard battery chicken cage system, one of Silver Star's larger designs, ensures excellent ventilation for chickens.

The European-sized poultry layers battery chicken cage features doors that measure 650mm in length, 625mm in depth, and 440mm in height, accommodating nine birds per door with 450 square centimeters per bird.

The European-sized poultry broilers battery chicken cage features doors measuring 1000mm in length, 1000mm in depth, and 440mm in height, accommodating twenty birds per door with 500 square centimeters per bird.





Advantages Of Battery Chicken Cage For Poultry Layers And Broilers:



1. The poultry layers and broilers battery chicken cage utilizes Q235 bridge wire, which ensures durability and resistance to bending over time.

2. The large size of the battery chicken cage systems ensures good ventilation, creating an optimal breeding environment for both layers and broilers chickens.

3. High-density breeding with battery chicken cages for poultry layers and broilers saves land and investment, making it easier to observe and manage the birds, and to select or gather weak ones.

4. The entire set of battery chicken cage equipment is fabricated using hot-dip galvanized processing, ensuring corrosion resistance and a lifespan of over 25 years.

5. Providing ample feed and maintaining proper hydration levels while ensuring uniform health among chickens helps minimize their exercise requirements, conserving energy and reducing feed consumption.

6. By completely separating chicken manure, allowing it to fall directly onto the belt, the chicken house experiences significantly reduced dust levels, lowers the risk of disease transmission from manure, and greatly decreases bird mortality rates.

7. This system is suitable for both closed and open chicken houses, providing automatic control of ventilation and temperature to effectively manage challenges posed by hot weather.

8.  The belt cleaning method significantly enhances air quality within the chicken house, thereby reducing the occurrence of certain diseases and ensuring high safety standards.

9. Achieving a low egg breakage rate while maintaining high cleanliness standards.





Specification Of European Standard Poultry Layers And Broilers Battery Chicken Cage:



Type H Poultry Layers Battery Chicken Cage
Model  Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3L54 1 9 3 54 450 650x625x440 650x1250x2220
H4L72 1 9 4 72 450 650x625x440 650x1250x2870
H5L90 1 9 5 90 450 650x625x440 650x1250x3520
H6L108 1 9 6 108 450 650x625x440 650x1250x4170
H8L144 1 9 8 144 450 650x625x440 650x1250x5470
Full equipment H Frame Battery Chicken Cage For Poultry Layers, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system, ventilation system



Type H Poultry Broilers Battery Chicken Cage
Model Door No. /cage Chicken No. /door No. of layers Capacity of one set of cage Area per bird (cm2/bird) Each door size(mm) Cage size/set (mm)
H3B60 1 20 3 60 500 1000x1000x440 1000x1000x2200
H4B80 1 20 4 80 500 1000x1000x440 1000x1000x2850
H3B90 1 30 3 90 500 1500x1000x440 1500x1000x2200
H4B120 1 30 4 120 500 1500x1000x440 1500x1000x2850
H3B156 4 13 3 156 500 740X850X440 1480X1750X2800
H4B208 4 13 4 208 500 740X850X440 1480X1750X3600
Full equipment H Frame Battery Chicken Cage For Poultry Broilers, Automatic feeding system, automatic drinking system, automatic manure removal system, automatic birds harvesting system, ventilation system




Why Use Battery Chicken Cage In Poultry Production?


1. Minimize feed waste and optimize productivity in layer farming.
2. Increased production
3.
Improved overall flock management
4. Reduce labor costs
5. No accidental deaths
6. Improved management of poultry waste
7. The cage systems can be reused.



Automatic Ventilation System For Layered Chicken Cages 4 Tiers Holds 120 Birds
