Baby Chick Cages In An H Type Configuration For Automatic Poultry Broiler Systems
Product Details
Poultry Broiler System Baby Chick Cages
,H Type Baby Chick Cages
H Type Baby Chick Cages Poultry Broiler Chicken Cage
Why to choose cage raising chicken ?
2:The use of automated drinking, feeding, manure cleaning, and egg collecting saves manpower and reduces raising costs; additionally, multi-layer cages occupy less space compared to floor raising, leading to higher land utilization and savings in construction and land costs.
3: The good isolation of the enclosed chicken house from the outside significantly decreases the chances of cross-contamination among chickens, benefiting epidemic disease prevention and control and reducing the costs associated with epidemic prevention.
Full automatic system of battery chicken cage:
Accessories of broiler chicken cage :
1). This new white PVC material trough resists compression, heat, and deformation, remaining unbroken. It boasts a lifespan of more than 15 years and can bear 100kg.
2). This 3MM U-type galvanized steel frame leg, made from a national standard 3MM thick steel plate, can bear 350kg. It is double-DIP galvanized for a lifespan of more than 15 years.
3). This automatic water nipple drinker offers a 360-degree rotating mechanism, available in ball type or spring type, using stainless steel and plastic materials.
4). This white PVC water pipe, made from new PVC material, resists deformation and high temperatures, ensuring durability. It prevents chemical reactions with water impurities, ensuring clean and healthy water for chickens, with a lifespan exceeding 15 years.
5). This regulator comes with a fully enclosed design, including a voltage regulator and filter.
Broiler chicken cage specification :
|
Tier
|
Cell size
|
Whole size
|
Capacity/set
|
Average area/bird
|
|
3-tiers
|
85*62.5*50 cm
|
85*220*260 cm
|
102 birds(1.5 kgs)
|
312.5 cm2
|
|
4-tiers
|
85*62.5*50 cm
|
85*220*325 cm
|
136 birds(1.5 kgs)
|
312.5 cm2
|
|
5-tiers
|
85*62.5*50 cm
|
85*220*390 cm
|
170 birds(1.5 kgs)
|
312.5 cm2
|
|
6-tiers
|
85*62.5*50 cm
|
85*220*455 cm
|
204 birds(1.5 kgs)
|
312.5 cm2
|
|
8-tiers
|
85*62.5*50 cm
|
85*220*585 cm
|
272 birds(1.5 kgs)
|
312.5 cm2
|
-
