H Type Complete Automatic Broiler Chicken Cage 4 Tiers Good Elasicity
Product Details
Complete Automatic Broiler Chicken Cage
,Broiler Chicken Cage 4 Tiers
,Good Elasicity Broiler Chicken Cage
Complete Automatic Broiler 4 Tiers Broiler Chicken Cage
H Type Complete Automatic Broiler Chicken Cage 4 Tiers
Advantage of chicken broiler cage:
1: Larger bearing capacity and more breeding space.
2: Hot dip galvanized sheet that is easy to clean
3: Cage mesh adopt bekaert galvanized alumunum wire
4:High intensity, good elasicity, it can effectively alleviate the chicken fatigue.
5: It not only greatly enhance the antirust effect, but also improve the cage surface smooth, to avoid the hurt of chicken scratch.
Accessories of broiler chicken cage :
1). The new white PVC material trough, compression, heat, deformation, not broken. Life span 15 years more. 100kg load-bearing.
2). 3MM U-type galvanized steel frame leg: National standard 3MM thick steel plate, U shape design.
350kg load-bearing. With double-DIP galvanizing, life span 15 years more.
3). Automatic water nipple drinker: 360-degree rotating design, ball type or spring type. Stainless steel and plastic.
4). White PVC water pipe: New PVC material, deformation, high temperature, difficult to damage. Impurities in the water will not produce a chemical reaction, thus ensuring the chickens can drink clean and healthy water. Useful life of 15 years more.
5). Regulator: Fully enclosed design, voltage regulator and with filter.
Broiler chicken cage specification :
|
Tier
|
Cell size
|
Whole size
|
Capacity/set
|
Average area/bird
|
|
3-tiers
|
85*62.5*50 cm
|
85*220*260 cm
|
102 birds(1.5 kgs)
|
312.5 cm2
|
|
4-tiers
|
85*62.5*50 cm
|
85*220*325 cm
|
136 birds(1.5 kgs)
|
312.5 cm2
|
|
5-tiers
|
85*62.5*50 cm
|
85*220*390 cm
|
170 birds(1.5 kgs)
|
312.5 cm2
|
|
6-tiers
|
85*62.5*50 cm
|
85*220*455 cm
|
204 birds(1.5 kgs)
|
312.5 cm2
|
|
8-tiers
|
85*62.5*50 cm
|
85*220*585 cm
|
272 birds(1.5 kgs)
|
312.5 cm2
|
-
