3Rows 28sets / Row A Type Wire Poultry Cage Farming Hens Equipments
Product Details
3 Rows Poultry Cage
,Hens Equipments Poultry Cage
,28 Sets / Row Poultry Cage
Automatic A Type Wire Chicken Cages Layer Poultry For Farming Poultry Hens Equipments
Introduction Of A Type Wire Chicken Cages Layer Poultry Hens Equipments
A type wire chicken cages layer poultry hens equipments are very popular in the farming and is designed both open and closed house all over the world, which is more suitable to be used in tropical zone area such as Africa, Southeast Asia and South Asia, South America etc, open house saves more electricity and good ventilation.With scientific design and effecient working process, solid structure, and one-site installation services, A frame layer chicken cage system with good quality which is certified by ISO9001:2015.
Automatic A Type Wire Chicken Cages Layer Poultry Farming Hens Project Plans:
|
10,000 Birds Wire Chicken Cages Layer Poultry Hens Farming Plan For 1 Shed
|
|
1. Manual A frame 3-floor poultry layer hens wire chicken cage: 3 rows, 28sets/row, poultry house size: 65x12x2.5m
|
|
2. Manual A type 4-tier chicken layer poultry hens cage: 2 rows, 32sets/row, poultry house size: 75x8x3m
|
|
3. Automatic A type 4-tier chicken farming poultry hend cage: 2 lines, 32sets/line, poultry house size: 78x8x3.5m
|
|
15,000 Birds Wire Chicken Cages Layer Poultry Hens Farming Plan For 1 House
|
|
1. Automatic Type A 4-layer wire chicken poultry farm cage: 47sets/line, 2lines, poultry shed size: 110x8x3.5m
|
|
2. Automated Type A 4-level layer poultry hens cage: 32sets/line, 3lines, poultry shed size: 78x12x3.5m
|
|
20,000 Birds Layer Poultry Farming Wire Chicken Cage Plan For One Poultry House
|
|
1. Automatic A type 4-level layer raising equipment battery cage: 42sets/row, 3rows, poultry shed size: 100x12x3.5m
|
|
25,000 Birds Poultry Hens Farming Wire Chicken Cage Plan For One Poultry Shed
|
|
1. Automatic A type 4-layer wire chicken cage system: 40sets/line, 4lines, poultry shed size: 95x15x3.5m
|
|
30,000 Birds Laying Farm Wire Chicken Cages System Plan For One Poultry Shed
|
|
1. Automatic A frame 4-layer poultry battery hens cage: 47sets/line, 4lines, poultry shed size: 110x15x3.5m
|
A Type Layer Poultry Hens Wire Chicken Cages Parameter:
| A Frame 3-Layer Poultry Hens Farming Wire Chicken Cages | ||||||
| Model | Capacity | Cage Size | Door Size | Birds No./Door | Door No. | Qty/20ft container |
| A3L90 | 90birds | 195x230x150cm | 39x38x38cm | 3birds/door | 5doors | 110sets |
| A3L96 | 96birds | 195x230x150cm | 48.7x38x38cm | 4birds/door | 4doors | 110sets |
| AD3L90 | 96birds | 172x230x160cm | 43x41x41cm | 4birds/door | 4doors | 105sets |
| A3L120 | 120 birds | 195x230x160cm | 39x41x41cm | 4birds/door | 5doors | 105sets |
| AD3L120 | 120 birds | 195x236x160cm | 39x45x41cm | 4birds/door | 5doors | 85sets |
| SS3L120 | 120birds | 215x230x160cm | 43x41x41cm | 4birds/door | 5doors | 100sets |
| A Type 4-Tier Poultry Layer Farming Wire Chicken Cage | ||||||
| Model | Capacity | Cage Size | Cell Size | Birds No./Cell | Cell No. | Qty/20ft container |
| A4L120 | 120birds | 195x230x190cm | 39x38x38cm | 3birds/cell | 5cells | 80sets |
| A4L128 | 128birds | 195x230x190cm | 48.7x38x38cm | 4birds/cell | 4cells | 80sets |
| AD4L120 | 128birds | 172x230x200cm | 43x41x41cm | 4birds/cell | 4cells | 78sets |
| A4L160 | 160 birds | 195x230x200cm | 39x41x41cm | 4birds/cell | 5cells | 78sets |
| AD4L160 | 160 birds | 195x236x200cm | 39x45x41cm | 4birds/cell | 5cells | 65sets |
| SS4L160 | 160birds | 215x230x200cm | 43x41x41cm | 4birds/cell | 5cells | 75sets |
Type A Layer Poultry Hens Wire Chicken Cage Features:
1. Number of chicken each unit area far exceeds the flating breeding way,it can increase 50% to 100%;
2. Chicken manure and chicken are completely isolated.Manure can be directly down to the ground,house dust greatly reduced,less chance of disease through infected feces,greatly reduced the morality of chicken;
3. Chicken limited to the minimum amount of exercise,energy consumption,save feed;
4. Easy to observe birds,clustering or choose amoy easily;
5. Have sufficient feed,water position and health uniformity are better for chicken
6. Can be avoided raising the required level of expenditure litter
7. Egg breakage rate,high cleanliness
8. Disability is reduced significantly
9. Low labor intensity
-
