A Type Layer Egg Laying Chicken Cage 160 Birds With Automatic Feeding System
Product Details
160 Birds Layer Chicken Cage
,Automatic Feeding System Layer Chicken Cage
,A Type Layer Chicken Cage
A Type Layer Egg Laying Chicken Cage System With Automatic Feeding System
Product Description
1. A type battery layer chicken cage
2. 3tiers, 4tiers,5 tiers
3:Q235 double hot galvanized anti-corrosion
4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.
A Type Layer Chicken Cage Size
| A Type Layer Chicken Cage | |||||||
| Cage size/cm | Door No. /cage | Chicken No. /door | No. of tier | Birds Qty/set | Area per bird (cm2/bird) | Each door size(cm) | Unit cage size(cm) |
| 195*38*38 | 5 | 3 | 3 | 90 | 494 | 39x38x38 | 195x230x150 |
| 195*38*38 | 5 | 3 | 4 | 120 | 494 | 39x38x38 | 195x230x190 |
| 195*41*41 | 5 | 4 | 3 | 90 | 533 | 39x41x41 | 195x230x160 |
| 195*41*41 | 5 | 4 | 4 | 120 | 533 | 39x41x41 | 195x230x200 |
| 195*41*41 | 4 | 4 | 3 | 96 | 499 | 48.7x41x41 | 195x230x160 |
| 195*41*41 | 4 | 4 | 4 | 128 | 499 | 48.7x41x41 | 195x230x200 |
| 195*45*41 | 5 | 4 | 3 | 120 | 438 | 39x45x41 | 195x236x160 |
| 195*45*41 | 5 | 4 | 4 | 160 | 438 | 39x45x41 | 195x236x200 |
| 172x41x41 | 4 | 4 | 3 | 96 | 440 | 43x41x41 | 172x230x160 |
| 172x41x41 | 4 | 4 | 4 | 128 | 440 | 43x41x41 | 172x230x200 |
| 215x41x41 | 5 | 4 | 3 | 120 | 440 | 43x41x41 | 215x230x160 |
| 215x41x41 | 5 | 4 | 4 | 160 | 440 | 43x41x41 | 215x230x200 |
| Full equipment | Layer chicken cage body, Automatic feeding machine, automatic drinking system, automatic egg collection and automatic manure cleaning system | ||||||
A Type Layer Chicken Cage Including
1: Cage with drinking system (Basic configuration, manual)
2: Automatic feeding system (Not mandatory option)
3: Automatic drinking system (Not mandatory option)
4: Automatic manure cleaning system (we have two types, Belt type and scraper type ) (Not mandatory option)
5: Automatic ventilation cooling system (Close house need it, Open house don't need it)
A Type Layer Chicken Cage Advantage
1.A Type Layer Chicken Cage can be designed both open and close house all over the world.
2.It is more suitable to be used in tropical zone such as Africa,Southeast Asia and South Asia Countries.
3.Ventilation performance is better than H type.
4.Economical and practical
-
