4 Tiers Chicken Egg Layer Battery Cage For Tanzania Poultry Farm Automatic Q235
Product Details
Automatic Battery Chicken Cage
,4 Tiers Battery Chicken Cage
,Poultry Farm Battery Chicken Cage
4 Tiers Chicken Egg Layer Battery Cage for Tanzania Poultry Farm Automatic Battery Cages
Product Description
(1)Tiers:3,4,5,6,8 leves/floors
(2)Material:Q235 Hot-Dipped Galvanized,Zinc thickness: 275g/㎡
(3)Frame:Material of leg of frame is hot-dip galvanized steel with thickness: 2mm
(4)Feed trough:Material: hot-dip galvanized steel. Thickness: 1.0mm.
(5)Design:Fully Automatic Poultry Breeding Layer Egg Chicken Cage Equipment
(6)Fully Automatic System Including Egg Chicken Farm Layer Chicken Cages Body,Egg Layer Chicken Hens Battery Cage Frame,Feeders,automatic drinking system,on-rail hopper feeding system,manure removal stystem,egg collection system,Ventilation System etc
H Type Layer Battery Cage Size
| Tier | Cell Size/ mm | Cage Size/ mm | Birds Qty |
| 3 | 650x625x500 | 650x1250x2220 | 54 |
| 4 | 650x625x500 | 650x1250x2870 | 72 |
| 5 | 650x625x500 | 650x1250x3520 | 90 |
| 6 | 650x625x500 | 650x1250x4170 | 108 |
| 8 | 650x625x500 | 650x1250x5470 | 144 |
| 3 | 450x600x410 | 1830x1200x2140 | 144 |
| 4 | 450x600x410 | 1830x1200x2790 | 192 |
| 5 | 450x600x410 | 1830x1200x3440 | 240 |
| 6 | 450x600x410 | 1830x1200x4090 | 288 |
| 8 | 450x600x410 | 1830x1200x5390 | 384 |
| Cage Body |
1. Size: 650x625x500mm, 430x500x410mm; 2. Material: Hot dipped galvanized; 3. Feed trough:Zn-Al material. Thickness: 1.0mm. 4. Can be designed into 3, 4, 5, 6, 8, 9, 10 Tiers; 5. Capacity:54-384 birds/set |
||
| Automatic Hopper Feeding Machine Equipment |
1. Hopper:Each tier with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel 2. Traction Device :Power of motor:0.75kw,tow rope: pp rope with 14mm,speed:8.67m/minute. 3. Track of Trolley:Hot-dip galvanized steel with 48mm*2.75mm. 4. Head and end frame:Hot-dip galvanized steel with 40mm*60mm*3mm. 5.Silos |
||
| Automatic Drinking System |
1. Nipple Drinkers 2. Water Pipes 3. Water Pressure regulator 4. Filter 5. Medical pump
|
||
| Automatic Egg Collecting Machine |
1. Hot-dip galvanized 1.5mm side plate,speed 4m/min. 2. Egg guider:Hot-dip galvanized with thickness 1mm,configuration with stretching device. 3. Egg belt:100mm width 4. Crosswise egg conveyor |
||
| Automatic Poultry Manure Removal Machine |
1. Belt type manure cleaning machine:Hot-dip galvanized 2. Manure cleaning belt:Material is PP, Thickness is 1.2mm.Width is 1.2m/ 1.25m. 3. Bracket for manure cleaning belt:hot-dip galvanized steel, 1.5mm thickness. 4. Transverse manure conveying
|
||
| Environmental Controller | Fans, cooling pad, air inlets, intelligent controller |
-
BWe are happy with the chicken cage system. The communication was smooth and they provided good technical support before shipment.
-
MThe cages arrived well packed. Installation was easy with the drawings provided by the company.
-
WVery good quality and easy to install. The automatic system saves labor and improves efficiency. Worth the investment.
-
