160 Birds A Type Poultry Battery Chicken Layer Cages System For 10000 Birds
Place of Origin | China |
---|---|
Brand Name | Silverstar |
Certification | SGS, ISO9001, CE, SONCAP |
Model Number | A3L90,A3L96,A3L120,A4L120,A4L160 |
Minimum Order Quantity | 10 Set |
Price | $106-$136/ Set |
Packaging Details | FCL: Standard Export Sea Worthy Packaging LCL: Wooden Case Package |
Delivery Time | 15-30 days |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 2000 Set / Week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Name | 160 Birds A Type Poultry Battery Chicken Layer Cages System | Keywords | Layer Chicken Cage |
---|---|---|---|
Material | Q235A Hot /Cold Dipped Galvanized Steel Wire Mesh | Tier | 3 Or 4 Tiers |
Capacity | 90 /96/ 120/128/160 Birds | MOQ | 10 Set |
Warranty | 1 Year | Life Span | More Than 20 Years |
High Light | 160 Birds Chicken Layer Cages,Battery Chicken Layer Cages |
160 Birds A Type Poultry Battery Chicken Layer Cages System For 10000 Birds
A Type Battery Layer Cage Specification
(1)Tiers:3 or 4 tier
(2)Material:Q235 national bridge steel, double cold galvanized or hot dip galvanizing, zinc thickness: 275g/㎡
(3)Cage frame :Material of leg of frame is U type hot-dip galvanized steel with thickness: 3mm
(4)Feed trough:Material: Pure white pvc or hot dipped galvanized or Zinc-Aluminum steel
(5)Design: Can be manual cage, semi-automatic or automatic as your request .
(6)Fully Automatic System Including Layer Hens Battery Cage Body, Layer Battery Cage Frame, Feeders, automatic drinking system,on-rail hopper feeding system, manure removal stystem, egg collection system, Ventilation System etc
A Type Layer Chicken Cage Size
A Type Layer Chicken Cage | |||||||
Cage size/cm | Door No. /cage | Chicken No. /door | No. of tier | Birds Qty/set | Area per bird (cm2/bird) | Each door size(cm) | Unit cage size(cm) |
195*38*38 | 5 | 3 | 3 | 90 | 494 | 39x38x38 | 195x230x150 |
195*38*38 | 5 | 3 | 4 | 120 | 494 | 39x38x38 | 195x230x190 |
195*41*41 | 5 | 4 | 3 | 90 | 533 | 39x41x41 | 195x230x160 |
195*41*41 | 5 | 4 | 4 | 120 | 533 | 39x41x41 | 195x230x200 |
195*41*41 | 4 | 4 | 3 | 96 | 499 | 48.7x41x41 | 195x230x160 |
195*41*41 | 4 | 4 | 4 | 128 | 499 | 48.7x41x41 | 195x230x200 |
195*45*41 | 5 | 4 | 3 | 120 | 438 | 39x45x41 | 195x236x160 |
195*45*41 | 5 | 4 | 4 | 160 | 438 | 39x45x41 | 195x236x200 |
172x41x41 | 4 | 4 | 3 | 96 | 440 | 43x41x41 | 172x230x160 |
172x41x41 | 4 | 4 | 4 | 128 | 440 | 43x41x41 | 172x230x200 |
215x41x41 | 5 | 4 | 3 | 120 | 440 | 43x41x41 | 215x230x160 |
215x41x41 | 5 | 4 | 4 | 160 | 440 | 43x41x41 | 215x230x200 |
A Type Chicken Cage Equipment Advantage
1. A type cage, simple operation, sturdy and durable;
2. The chicken cage is encrypted with a net and a bottom net, which effectively prevents chickens from pecking feathers and anus, and reduces the egg breaking rate and laying hen fatigue syndrome
3. The whole set of products adopts hot-dip galvanizing or cold-dip galvanizing process, and has a long service life;
4. The thickened structure of the front mesh steel wire is firmer, the structure is reasonable, and the energy consumption is low;
5. The unique horizontal door design, the cage door space is larger, and the position of chicken feeding can be changed arbitrarily, which effectively solves the problem of crowding chickens when they eat and ensures that the chickens eat more evenly
6. It is used by many customers at home and abroad, and the effect is excellent
The a type chicken cage is suitable for small and medium-sized farmers, with reasonable cost and large breeding scale, which can effectively improve the income of small and medium-sized farmers. Cascading chicken cages, exquisite materials, long service life, high breeding density, suitable for large-scale breeding, high degree of automation and easy management.
.
