Poultry Farming Chicken Layer Cages Fully Automatic Battery System H Type Egg
Product Details
Poultry Farming Chicken Layer Cages
,10Tiers H Type Chicken Cages
,384 birds/ Set Chicken Cages
Poultry Farming Fully Automatic H Type Egg Chicken Layer Cages
Product Description
(1)Tiers:3,4,5,6,8 leves/floors
(2)Material:Q235 Hot-Dipped Galvanized,Zinc thickness: 275g/㎡
(3)Frame:Material of leg of frame is hot-dip galvanized steel with thickness: 2mm
(4)Feed trough:Material: hot-dip galvanized steel. Thickness: 1.0mm.
(5)Design:Fully Automatic Poultry Breeding Layer Egg Chicken Cage Equipment
(6)Fully Automatic System Including Egg Layer Chicken Cages Body,Cage Frame,Feeders,automatic drinking system,on-rail hopper feeding system,manure removal stystem,egg collection system,Ventilation System etc.
H type chicken layer cage is suitable for large-scale chicken farms. It is recommended for poultry farms rearing over 25000 birds. As a typical battery cage, H type chicken cage is well accepted by more and more livestock farms. The vertically stacked cages save more floor space, increase rearing number, reduce cost in manpower and management and eventually bring considerable profit for chicken growers.
H Type Layer Chicken Cage Size
| H Type Chicken Battery Cage | |||||||
| H Type Broiler Battery Cage | H Type Layer Battery Chicken Cage | ||||||
| Tier/ Floors | Cell Size/ cm | Cage Size/ cm | Birds Qty | Tier/ Floors | Cell Size/ cm | Cage Size/ cm | Birds Qty |
| 3 | 100x100x44 | 100x100x220 | 60 | 3 | 65x62.5x50 | 65x125x222 | 54 |
| 4 | 100x100x44 | 100x100x285 | 80 | 4 | 65x62.5x50 | 65x125x287 | 72 |
| 3 | 100x150x44 | 100x150x220 | 90 | 5 | 65x62.5x50 | 65x125x352 | 90 |
| 4 | 100x150x44 | 100x150x285 | 120 | 6 | 65x62.5x50 | 65x125x417 | 108 |
| 3 | 148x175x44 | 148x175x280 | 144 | 8 | 65x62.5x50 | 65x125x547 | 144 |
| 4 | 148x175x44 | 148x175x360 | 192 | 3 | 43x60x41 | 183x120x214 | 144 |
| 4 | 43x60x41 | 183x120x279 | 192 | ||||
| 5 | 43x60x41 | 183x120x344 | 240 | ||||
| 6 | 43x60x41 | 183x120x409 | 288 | ||||
| 8 | 43x60x41 | 183x120x539 | 384 | ||||
Advantage
1.The main material of the equipment is hot dip galvanized steel. The life time can reach 15-20 years.
2.Intensive management and full automatic system including feeding system, drinking system, egg collecting system, environmental control system, cleaning manure system can improve the rate of labor productivity and save the labor costs.
3.High-density breeding of up to 12 layers can be realized to save land and reduce construction investment and management costs.
4.Suitable for closed chicken shed, with automatic ventilation and temperature control system, to ensure that the environment of shed inside meets the needs of chickens.
-
