Husbandry Equipment Poultry Battery Cage Layer Chicken Animal A Type Q235
Product Details
Husbandry Equipment Poultry Battery Cage
,Layer Chicken Animal Poultry Battery Cage
,A Type Q235 Poultry Battery Cage
Poultry Husbandry Equipment A Type Battery Layer Chicken Cage Animal Cage
Product Description
1.A type battery layer cage
2. 3tiers, 4tiers,5 tiers
3:Q235 double hot galvanized anti-corrosion
4:Q235 national standard double hot galvanized bridge steel cage,hot galvanized steel feed trough,ball type automatic water equipment ,white PVC pipe ,3MM U type galvanized steel shelves,closed-end pressure-reducer;Al-Zn material feeding system,AL-Zn material manure cleaning system,ventilation system,lighting system,environment controlling system and so on.
A Type Layer Chicken Cage Including
1: Cage with drinking system (Basic configuration, manual)
2: Automatic feeding system (Not mandatory option)
3: Automatic drinking system (Not mandatory option)
4: Automatic manure cleaning system (we have two types, Belt type and scraper type ) (Not mandatory option)
5: Automatic ventilation cooling system (Close house need it, Open house don't need it)
A Type Layer Chicken Cage Size
| A Type 3 Tiers Layer Cage | ||||||
| Model | Capacity | Cage Size | Cell Size | Cell Capacity | Door | Qty/20ft container |
| 1 | 90birds | 195x230x150cm | 39x38x38cm | 3birds/cell | 5doors | 110sets |
| 2 | 96birds | 195x230x150cm | 48.7x38x38cm | 4birds/cell | 4doors | 110sets |
| 3 | 96birds | 172x230x160cm | 43x41x41cm | 4birds/cell | 4doors | 105sets |
| 4 | 120 birds | 195x230x160cm | 39x41x41cm | 4birds/cell | 5doors | 105sets |
| 5 | 120 birds | 195x236x160cm | 39x45x41cm | 4birds/cell | 5cells | 85sets |
| 6 | 120birds | 215x230x160cm | 43x41x41cm | 4birds/cell | 5cells | 100sets |
| A Type 4 Tiers Layer Cage | ||||||
| Model | Capacity | Cage Size | Cell Size | Cell Capacity | Door | Qty/20ft container |
| 1 | 120birds | 195x230x190cm | 39x38x38cm | 3birds/cell | 5doors | 80sets |
| 2 | 128birds | 195x230x190cm | 48.7x38x38cm | 4birds/cell | 4doors | 80sets |
| 3 | 128birds | 172x230x200cm | 43x41x41cm | 4birds/cell | 4doors | 78sets |
| 4 | 160 birds | 195x230x200cm | 39x41x41cm | 4birds/cell | 5doors | 78sets |
| 5 | 160 birds | 195x236x200cm | 39x45x41cm | 4birds/cell | 5cells | 65sets |
| 6 | 160birds | 215x230x200cm | 43x41x41cm | 4birds/cell | 5cells | 75sets |
Advantage
1. 3-10 tiers battery cage: Reasonable high-density raising meets different needs. Reduced energy costs for heating or cooling.
2. Q235 High Quality Steel Material from Brand
Manufacturers: 275g/m² Hot-dip galvanized steel.Stronger equipment and 20 years service life.
Numerical Control Process Technology: High precision, easy to install,operate smoothly.
3. 2.15mm High Quality Steel Mesh : Bear high weight with long-lasting better elasticity.
Two Reinforcing Ribs at Each Bottom Mesh: 50kg/㎡ Load-bearing Bottom Mesh.
4. Reasonable Distance in Cages: Small temperature difference inside and outside the cage.
Two Lines Stainless Steel Nipple Pipe: The water supply is safe and adequate.
450cm²/bird: Happy chickens lay more eggs.
5. Bottom Mesh with 8 ° Slope: The egg rolls down gently.
PVC Egg Baffle: Prevent chicken peck eggs.
Top Mesh: Prevent the birds peck manure and scurry.
Sliding Grids: Easy to move birds, no chicken escape.
6. Deep ‘V’ Feed Trough with Inner Rim:
Saving feed cost.
Automatic Feeding System:
Every chicken has adequate feed intake
-
