1.4m 1.75m Automatic Poultry Manure Belt System H Chicken Cage Use
| Place of Origin | China |
|---|---|
| Brand Name | Silver Star |
| Certification | ISO9001, SGS |
| Model Number | YXPM5 |
| Minimum Order Quantity | 1 Set |
| Price | 600-2400USD/Set |
| Packaging Details | Standard Exporting Packaging Or As Customers' Request |
| Delivery Time | 7-15 working days after advanced payment |
| Payment Terms | T/T, Western Union, D/A, D/P, L/C |
| Supply Ability | 50000sets/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Keywords | Poultry Manure Belt System | Manure Cleaning Type | Belt Or Scraper Manure Collector |
|---|---|---|---|
| Material | Hot Galvanized Or Stainless Steel, Zinc-aluminum | Belt Width | 1m, 1.25m, 1.4m, 1.75m |
| Lateral Belt | 6mm Rubber Belt, Green Color | Use For | Type A Or H Chicken Cage Poultry Farm |
| Local Service | Indonesia, Philippines, Thailand, Ecuador, Algeria, Ghana, Kenya, Nigeria, Panama | HS Code | 84362900 |
| High Light | 1.4m Poultry Manure Belt System,1.75m Poultry Manure Belt System,1.4m automatic manure removal system |
||
Product Description
1.4m 1.75m Automatic Poultry Manure Belt System H Chicken Cage Use
Introduction
poultry chicken manure belt, poultry quail manure belt, poultry duck dung belt, quail dung manure belt, chicken stool belt, quail stool belt, manure conveyor belt, polypropylene belt, manure removal belt, manure
cleaning belt
Poultry Farm Manure Cleaning Remove Equipment Advantages
1. Manure conveyor belt for poultry dung remover is a thickened PP material, which has strong corrosion resistance, strong environmental adaptability and long life. Moreover, the wear rate of the belt is very low when c manure, and it can be used for ten to twenty years, which can carry heavy objects, generally one square can carry the limit of 5000N force.
2. The conveyor belt manure cleaning motor produced by our company uses a cycloid reducer, and the multi-layers can be equipped with a straight gear reducer.
3. High-carbon steel is used for the scraping mouth, and some use high-thickness galvanized steel, which can withstand objects harder than itself without deformation, and the scraper is well-made.
4. High working efficiency, chicken manure can be automatically transfered out timely, avoiding overnight chicken manure infection, preventing the occurrence of infectious diseases, automatic loading, and the height of chicken manure can be automatically adjusted according to the situation.
Manure Cleaning Remove System Technical Parameter
| Belt Type Manure Cleaning Remove System | Hot-dip galvanized 3mm side sheet, chain safety door with 1mm hot-dip galvanized steel or zinc-aluminum, running speed 3m/min.Motor:1.5kw |
| Poultry Litter Cleaning Belt | PP manure belt, which has high tensile strength to ensure a long service life.Thickness is 1.2mm. Width:1m,1.2m ,1.25m, 1.4m, 1.5m, 1.75m, 1.8m, 2.1m |
| Bracket For Poultry Dung Cleaning Belt | Hot dipped galvanized, 1.5mm thickness |
| Passive Roller | Spiral type cylinder,in the front. Anti deviation system is included. |
| Transversal manure conveying machine | Each chicken house is with 1 set, transverse and slope conveying is separate, the material is hot dipped galvanized; Manure belt: green rubber belt with 8mm thickness. Power:3kw, The transverse manure conveying system adopts rubber conveying belt. There is no leak of manure during transportation. |
Installation Precautions
1. It is required that the chicken house must be hardened, the ground is flat, there is no convexity and concave place, the slope control should not exceed 2 degrees up and down. The excrement should be 5-10 degrees lower on the other side. So that the water can be drained smoothly.
2. Place the cages straight and adjust the foot adjuster so that the height deviation between the two cages should not exceed 0.5 mm, and the distance between the legs should not exceed 0.5 mm.
3. Main engine should be firmly fixed, also the head and tailstock should be firmly fixed to the ground without loosening.
4. Install manure belt or scraper, and check whether the manure belt and the manure baffle are suitable.
5. The electrician installs the wiring and control line, and finds the position of the travel switch, and fixes it firmly;
6. The controller must contain a leakage protection device;
7. The test running is performed by a person on the control panel in a jog mode, and multiple persons should cooperate to ensure that there are no scratches, jams, deflection, etc. in the equipment. If problems are found, find out the reasons and solve them in time. Start and run when it is confirmed that there is no error;
8. If the operation is stable, the manure removal is uniform and there is no too much noise (less than 40 decibels). There is not much jitter. That is qualified.
