H Type 4 Tiers Automatic Broiler Feeder 1800x1200x410mm
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Chicken Feeder Cages For Layers | Product Name | Cages For Layers |
|---|---|---|---|
| Application | Poultry Field Cages For Layers | Material | Hot Dip Galvanized Cages For Layers |
| Color | Silver Cages For Layers | Usage | Chicken Raising Cages For Layers |
| Feature | Durable Cages For Layers | Advantage | Long Time Used Cages For Layers |
| Size | 650*1250*2300(cm) Cages For Layers | Capacity | 200-300 Chickens/set Cages For Layers |
| High Light | Automatic Broiler Feeder 1800x1200x410mm,Chicken Farm Feeding System H Type,Broiler Automatic Feeding System 4 Tiers |
||
Product Description
H type layer cage.
Hopper Trolley Feeding Machines Techinical Parameter
1. Chicken Cage Feed Hopper: Each layer of chicken cage with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel
2. Traction Device: Power of motor:0.75kw,tow rope: pp rope with 14mm, speed: 8.67m/minute.
3. Track of Trolley: Hot dip galvanized steel with 48mm*2.75mm.
4. Head and End Frame: Hot-dip galvanized steel with 40mm*60mm*3mm.
5. Operation: Each line of feeding machine can be operated seperately.
6. Auger Transverse: The feeding trolley carts is conneted with the silo by the transverse feeding auger.
7. Application: Suit for both A and H frame poultry laying hens cage, poultry broiler cage, poultry brooder cage etc.
H Type Egg Layer Chicken Cage Size
| H Type Egg Layer Chicken Cage | |||||||||
| Model | Length(mm) | Width(mm) | Height(mm) | Cells Qty | Birds Qty/Set | Each Bird Area/cm2 | |||
| 3 Tiers | 1800 | 1200 | 2140 | 4 | 144 | 450 | |||
| 4 Tiers | 1800 | 1200 | 2790 | 4 | 192 | 450 | |||
| 5 Tiers | 1800 | 1200 | 3440 | 4 | 240 | 450 | |||
| 6 Tiers | 1800 | 1200 | 4090 | 4 | 288 | 450 | |||
| 8 Tiers | 1800 | 1200 | 5390 | 4 | 384 | 450 | |||
| 3 Tiers | 650 | 1250 | 2220 | 1 | 54 | 450 | |||
| 4 Tiers | 650 | 1250 | 2870 | 1 | 72 | 450 | |||
| 5 Tiers | 650 | 1250 | 3520 | 1 | 90 | 450 | |||
| 6 Tiers | 650 | 1250 | 4170 | 1 | 108 | 450 | |||
| 8 Tiers | 650 | 1250 | 5470 | 1 | 144 | 450 | |||
| Full Automatic Poultry Laying Hens Farm Equipment: Poultry Chicken Egg Layer Cage Body, Automatic Drinking, Automatic Hopper Trolley Feeding, Automatic Egg Collection, Automatic Manure Faces Removal, Ventilation System, Lighting System, Environmental Controller |
|||||||||
Why To Choose Chicken Battery Cage Raising Chicken ?
1. The environment of poultry chicken house is controllable, which is conducive to the physiological and production needs of chicken.
2. Automatic drinking, feeding, manure cleaning, eggs collecting, saving labors, reducing breeding cost, multi-layer chicken cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.
3. Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.
