Quality H Type 4 Tiers Automatic Broiler Feeder 1800x1200x410mm factory

H Type 4 Tiers Automatic Broiler Feeder 1800x1200x410mm

Name: H Type 4 Tiers Automatic Broiler Feeder 1800x1200x410mm
Brand: Henan Silver Star Poultry Equipment Co.,LTD
SKU: H type cage
Price: 1,250.00 USD
Availability: InStock

Basic Properties

Place of Origin: China

Brand Name: Silver Star

Certification: ISO 9001

Model Number: H type cage

Trading Properties

Minimum Order Quantity: 10

Standard Packaging: container, wooden case

Delivery Time: 20-40 days

Payment Terms: T/T

Supply Ability: 100 set 30 days

4tier poultry farming equipment

H type layer cage. Hopper Trolley Feeding Machines Techinical Parameter 1. Chicken Cage Feed Hopper: Each layer of chicken cage with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel 2. Traction Device: Power of motor:0.75kw,tow rope: pp rope with 14mm, speed: 8.67m/minute. 3. ...

Product Details

Highlight:

Automatic Broiler Feeder 1800x1200x410mm

,

Chicken Farm Feeding System H Type

,

Broiler Automatic Feeding System 4 Tiers

Name: Chicken Feeder Cages For Layers

Product Name: Cages For Layers

Application: Poultry Field Cages For Layers

Material: Hot Dip Galvanized Cages For Layers

Color: Silver Cages For Layers

Usage: Chicken Raising Cages For Layers

Feature: Durable Cages For Layers

Advantage: Long Time Used Cages For Layers

Size: 650*1250*2300(cm) Cages For Layers

Capacity: 200-300 Chickens/set Cages For Layers

Product Description

H type layer cage.

Hopper Trolley Feeding Machines Techinical Parameter

1. Chicken Cage Feed Hopper: Each layer of chicken cage with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel

2. Traction Device: Power of motor:0.75kw,tow rope: pp rope with 14mm, speed: 8.67m/minute.

3. Track of Trolley: Hot dip galvanized steel with 48mm*2.75mm.

4. Head and End Frame: Hot-dip galvanized steel with 40mm*60mm*3mm.

5. Operation: Each line of feeding machine can be operated seperately.

6. Auger Transverse: The feeding trolley carts is conneted with the silo by the transverse feeding auger.

7. Application: Suit for both A and H frame poultry laying hens cage, poultry broiler cage, poultry brooder cage etc.

H Type Egg Layer Chicken Cage Size

H Type Egg Layer Chicken Cage
Model	Length(mm)	Width(mm)	Height(mm)	Cells Qty	Birds Qty/Set	Each Bird Area/cm2
3 Tiers	1800	1200	2140	4	144	450
4 Tiers	1800	1200	2790	4	192	450
5 Tiers	1800	1200	3440	4	240	450
6 Tiers	1800	1200	4090	4	288	450
8 Tiers	1800	1200	5390	4	384	450
3 Tiers	650	1250	2220	1	54	450
4 Tiers	650	1250	2870	1	72	450
5 Tiers	650	1250	3520	1	90	450
6 Tiers	650	1250	4170	1	108	450
8 Tiers	650	1250	5470	1	144	450
Full Automatic Poultry Laying Hens Farm Equipment: Poultry Chicken Egg Layer Cage Body, Automatic Drinking, Automatic Hopper Trolley Feeding, Automatic Egg Collection, Automatic Manure Faces Removal, Ventilation System, Lighting System, Environmental Controller

Why To Choose Chicken Battery Cage Raising Chicken ?

1. The environment of poultry chicken house is controllable, which is conducive to the physiological and production needs of chicken.

2. Automatic drinking, feeding, manure cleaning, eggs collecting, saving labors, reducing breeding cost, multi-layer chicken cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.

3. Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.

H Type 4 Tiers Automatic Broiler Feeder 1800x1200x410mm
