Zinc-Alu Automatic Feeding Machine For Poultry , SGS 1.2mm Broiler Feeding System

Place of Origin China
Brand Name Silver Star
Certification ISO 9001
Model Number H type cage
Minimum Order Quantity 10
Packaging Details container, wooden case
Delivery Time 20-40 days
Payment Terms T/T
Supply Ability 100 set 30 days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Name Chicken Feeder Cages For Broiler Product Name Cages For Broiler
Application Poultry Field Cages For Broiler Material Hot Dip Galvanized Cages For Broiler
Color Silver Cages For Broiler Usage Chicken Raising Cages For Broiler
Feature Durable Cages For Broiler Advantage Long Time Used Cages For Broiler
Size 650*1250*2300(cm) Cages For Broiler Capacity 200-300 Chickens/set Cages For Broiler
Leave a Message
Product Description

Yin Xing Poultry Equipment Customized Multi-Style Multi-broiler Chicken Cage

Product introduction



Hopper Trolley Feeding Machine Information


Hopper trolley feeding machine is running in most chicken farms projetcts with zinc-aluminum alloy steel material. The hopper trolley feeding mode conveys the feed in the silo to the driving hopper of the chicken house through the lateral feeding position. The cart runs back and forth, the homogenizer distributes the feed uniformly in the trough, and the feed amount can be adjusted. This process works completely in accordance with the pre-set automatic control program. With a trough with an inner edge, the chicken will not throw out the feed when eating, which saves the cost of feeding. There are feed levelers at both ends of each feed line. Regularly clean up the long-term residual feed in the trough to prevent feed deterioration and waste.



Hopper Trolley Feeding Machines Techinical Parameter


1. Chicken Cage Feed Hopper: Each layer of chicken cage with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel

2. Traction Device: Power of motor:0.75kw,tow rope: pp rope with 14mm, speed: 8.67m/minute.

3. Track of Trolley: Hot dip galvanized steel with 48mm*2.75mm.

4. Head and End Frame: Hot-dip galvanized steel with 40mm*60mm*3mm.

5. Operation: Each line of feeding machine can be operated seperately.

6. Auger Transverse: The feeding trolley carts is conneted with the silo by the transverse feeding auger.

7. Application: Suit for both A and H frame poultry laying hens cage, poultry broiler cage, poultry brooder cage etc.


H Type Egg Layer Chicken Cage Size


H Type Egg Layer Chicken Cage
Model Length(mm) Width(mm) Height(mm) Cells Qty Birds Qty/Set Each Bird Area/cm2
3 Tiers 1800 1200 2140 4 144 450
4 Tiers 1800 1200 2790 4 192 450
5 Tiers 1800 1200 3440 4 240 450
6 Tiers 1800 1200 4090 4 288 450
8 Tiers 1800 1200 5390 4 384 450
3 Tiers 650 1250 2220 1 54 450
4 Tiers 650 1250 2870 1 72 450
5 Tiers 650 1250 3520 1 90 450
6 Tiers 650 1250 4170 1 108 450
8 Tiers 650 1250 5470 1 144 450
Full Automatic Poultry Laying Hens Farm Equipment: Poultry Chicken Egg Layer Cage Body, Automatic Drinking, Automatic Hopper Trolley Feeding, Automatic Egg Collection, Automatic Manure Faces Removal, Ventilation System, Lighting System, Environmental Controller


Selection of broiler cages


In determining breeding scale, sites should be selected with due regard to the need for basic farming space, if green belts and refuge zones are taken into account, even though they may expand in the future, some land may be appropriately appropriated at least in the overall planning. Generally speaking,430 mu (1 mu 667 meters),645 mu,860 mu, is a more appropriate auxiliary planning. According to the experience of this chicken farm, the chicken house is generally required to be 120 meters long by 13 meters wide, and the chicken house space is 10-15 meters, and if there is no lateral ventilation, the chicken house space is 2-4 meters. In order to reduce the construction site investment and improve the insulation effect, we can establish a joint chicken coop. Considering the accessibility of Internet and dirt roads, the basic requirement is that the land should be at least 150 meters wide (generally east to west) and 180 to 300 meters long (generally north to south).


Cage-raised coop has the advantages of increasing feed density, reducing feed consumption, reducing diarrhea and coccidiosis, improving labor efficiency, convenient management and making full use of coop space. Some chicken farms use 3 or 4 layers of overlapping cages, the whole process of raising chickens, namely from the first day of raising chickens outside the cage to raise chickens, more binding, improve the utilization rate of chicken farms and chicken farms, but also for chicken management.Zinc-Alu Automatic Feeding Machine For Poultry , SGS 1.2mm Broiler Feeding System 0Zinc-Alu Automatic Feeding Machine For Poultry , SGS 1.2mm Broiler Feeding System 1
