H Type Welded Wire Mesh Chicken Poultry Cage
Product Details
H Type Chicken Poultry Cage
H Type Welded Wire Mesh Chicken Poultry Cage
Detailed information of Chicken Battery Cages:
Material: Q235 national standard bridge steel cages, white PVC trough, Ball-type automatic water equipment, white PVC pipe, 3MM U-type galvanized Steel shelves, closed-end regulator.
The nipple drinker: Automatic water valve device: 360-degree rotating design, traffic, water Enough. Watertight. Chicken is easy to meet drinking water needs. Imports of stainless steel Sphere. Useful life of 15-20 years. 3 years of damage or leakage, free replacement. (Except Artificial damage)
Trough: The new white PVC trough, compression heat and deformation, not broken.
Service life of 15 -20 years. Ability to withstand compression: Any adult can walk on it.
The pipe: White PVC pipe: New PVC material, deformation, high temperature, difficult To damage. Impurities in the water will not produce a chemical reaction, thus ensuring The chickens can drink clean and healthy water. Useful life of 15 years.
The pressure reducer: Closed regulator: Fully enclosed design, voltage regulator and Filter with one, you can adjust the length of the sheds any water pressure. Every chicken Cage line need three pressure reducers. If you have two lines, you need six Leg support: 3MM U-type galvanized steel shelf, national standard 3MM thick steel Plate, U shape design. Can withstand pressure of 350 kg. With double-dip galvanizing, The age of 15 -20 years.
Layer chicken cage specification :
| H type 3/4tiers layer chicken cage | |||||||
| Model | Type | Capacity | Cage size | Cell size | Cell capacity | Door | Avergae area |
| 1 | H type 3 tiers | 54 birds/set | 65*218*265cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
| 2 | H type 4 tiers | 72 birds/set | 65*218*330cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
| 3 | H type 5 tiers | 90 birds/set | 65*218*395cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
| 4 | H type 6 tiers | 108 birds/set | 65*218*460cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
| 5 | H type 7 tiers | 126 birds/set | 65*218*595cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
| 6 | H type 8 tiers | 144 birds/set | 65*218*660cm | 65*62.5*50cm | 9birds/cell | 1door | 451.38cm2 |
-
