HDG Automatic Poultry Feeding System 8.67m/Min 0.75kw Chicken Cage Feeder

Place of Origin China
Brand Name Silver Star
Certification ISO9001, SONCAP
Model Number YXH4L192, YXHF3
Minimum Order Quantity 50Set
Price 95-285USD/ Set
Packaging Details FCL: Standard exporting packaging; LCL: Wooden box, carton packaging
Delivery Time in 30 working days after deposit
Payment Terms T/T, Western Union, L/C, D/A, D/P
Supply Ability 20000sets/week

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Product Name Hot-dip Galvanized Wire Poultry Layer Cages With Auto Feeder Cage Type A Or H Frame Of Layer Cages
Usage Animal Husbandry Layer Farming Equipment Cage Stand U Type Steel Cage
Wire Diameter 3-6mm, Poultry Cage Feature Auto Feeder, Zinc-aluminum Steel
Driving Motor 380/220v, 0.75kw, Or Be Customized Surface Treatment Hot-dip Galvanized Wire
Local Service Ecuador, Kenya, Algeria, Indonesia, Panama, Nigeria, Ghana, Philippines, Uzbekistan, Bangladesh HS Code 8462900
High Light

HDG Automatic Poultry Feeding System


8.67m/min Automatic Poultry Feeding System


0.75kw chicken cage feeder

Leave a Message
Product Description

      Hot-Dip Galvanized Wire Poultry Layer Cages With Auto Feeder



Hot-Dip Galvanized Wire Poultry Layer Cages Information


Poultry layer cages wire mesh is processed by hot-dip galvanized after welding process and adopted with 400um thickness for zinc-layer, and the corrosion resistance is 3-4 times that of the general surface treatment, more than 25 years of lifespan.


What is the difference between cold galvanized and hot galvanizing?

Cold galvanized: smooth and bright surface, galvanized layer: 20-30g/m2.

In a humid condition, it is easy to be rusted, but it will not affect the use after rust. Life service : 15 years

Hot-dip galvanizing: The surface zinc thickness can reach about 500g/m2, with high strength and corrosion resistance. Lifespan: Over 25 years



Auto Feeder Structure


1. Poultry Layer Cage Feed Hopper: Each tier of chicken cage with two hoppers, thickness is 1.2mm, material is hot-dip galvanized steel

2. Traction Device: Power of motor:0.75kw,tow rope: pp rope with 14mm, speed: 8.67m/minute.

3. Track of Trolley: Hot dip galvanized steel with 48mm*2.75mm.

4. Head and End Frame: Hot-dip galvanized steel with 40mm*60mm*3mm.

5. Operation: Each line of feeding machine can be operated seperately.

6. Auger Transverse: The feeding trolley carts is conneted with the silo by the transverse feeding auger.

7. Application: Suit for both A and H type poultry layer cage, poultry broiler cage, poultry brooder cage etc.


Poultry Layer Cage Dimension


A Shaped Structure Poultry Layer Cage
Model Length(mm) Width(mm) Height(mm) Cells Qty Birds Qty/Set Each Bird Area/cm2
3 Tiers 1950 2300 1500 5 90 494
4 Tiers 1950 2300 1900 5 120 494
3 Tiers 1950 2300 1600 4 96 462
4 Tiers 1950 2300 2000 4 128 462
3 Tiers 2150 2300 1600 5 120 440
4Tiers 2150 2300 2000 5 160 440
3Tiers 2150 2360 1600 5 120 483
4 Tiers 2150 2360 2000 5 160 483
3 Tiers 1720 2360 1600 4 96 440
4 Tiers 1720 2360 2000 4 128 440
H Frame Egg Chicken Poultry Layer Cage
Model Length(mm) Width(mm) Height(mm) Cells Qty Birds Qty/Set Each Bird Area/cm2
3 Tiers 1800 1200 2140 4 144 450
4 Tiers 1800 1200 2790 4 192 450
5 Tiers 1800 1200 3440 4 240 450
6 Tiers 1800 1200 4090 4 288 450
8 Tiers 1800 1200 5390 4 384 450
3 Tiers 650 1250 2220 1 54 450
4 Tiers 650 1250 2870 1 72 450
5 Tiers 650 1250 3520 1 90 450
6 Tiers 650 1250 4170 1 108 450
8 Tiers 650 1250 5470 1 144 450
Full Automatic Poultry Laying Hens Farm Equipment: Poultry Chicken Layer Cage Body, Automatic Drinking, Auto Feeder, Automatic Egg Collector, Automatic Manure Faces Cleaner, Ventilation System, Lighting System, Environmental Controller



Why To Choose Layer Poultry Farming Cage Raising Chicken ?


1. The environment of poultry chicken house is controllable, which is conducive to the physiological and production needs of chicken.

2. Automatic drinking, feeding, manure cleaning, eggs collecting, saving labors, reducing breeding cost, multi-layer battery cage saves more space than floor raising, high land utilization rate, saving chicken house construction and land cost.

3. Due to the good isolation between the close chicken house and the outside , the chance of cross contamination of chickens will be greatly reduced, which is conducive to the prevention and control of epidemic diseases, and save the cost of epidemic prevention.
